首要手艺参数：Main Technical Parameters

机型 Model	CLFQ-W1300	CLFQ-W1600
质料宽度 MAX.Width of raw material	1300mm	1600mm
放卷直径 Max.parent Web Diameter	Φ1200mm	Φ1200mm
收卷直径 Max.Rewinding Diameter	Φ1000mm	Φ1000mm
机器速率 Max.Machine Speed	10-300m/min	10-300m/min
资料厚度 Thickness of raw material	0.008-0.2mm	0.008-0.2mm
总功率 Total Power	19KW	23KW
分量 Machine Weight	4300kg	4800kg
形状尺寸 Overall Dimensions	2700×2900×1800mm	3000×2900×1800mm
分切宽度 Min.Slitting Width	50mm

可遵循物品恳请 定制大小设备。

Can be made according to the product requires spe🥀cial equi♛pment.

产品声明函配伍规模较超声波焊接机同用于各项大型的板料的模切，如30g/m2-300g/m2牛皮革纸、白打印机卡纸、淋膜纸、铝铂、PVC塑胶、锡纸等板料的模切、复卷等。机可及杭州特色1. 什么是服务器采纳异步伺服电机机械(矢量素材机械)放肆、主动的锥度张度，中部卷取体例。台式主机采纳调频变速，持之以恒加快速度通常情况下衡正常运作。2. 主动性计米、报警器保健作用。收卷去接纳A、B气胀轴调整布局，卸装控制便民。3. 放卷宽容微电子主动权纠偏批改作业风险管理体系，使不准则基本资料能普遍分切机。4. 圆刀纵切废边自觉释放装配线。5. 汽压式相互上料机，配气胀轴。6.导轨式自主下料机自动装配。

product manual

Scope of application

This machine is suitable for the slitting of various sup🍸er-large coils, such as slitting and rewinding of 30g/m2-300g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC plastic, tin foil and other coils.

Performance and characteristics

1. The machine adopts asynchronous servo motor (vector motor) control, automatic taper tension and center winding method. The main engine adopts frequency conversion speed regulation to maintain balanced operatio꧋n during acceleration.

2. Automatic meteri𓃲ng and alarm function. The winding adopts the A and B air expansion shaft structure, and the unloading operation is convenient.

3. Unwinding adopts photoelectric automatic corr🗹ection correction system to make irregular materials 💎cut normally.

4. The circular knife cuts the waste side 🦩automatic discharge device.

5. Hydraulic automatic feeding, wi𝓰th air expa🐼nsion shaft.

6. Rail type automatic cutting device.
